Product Details:
|
| Material: | Silicone Rubber | Width: | 50mm |
|---|---|---|---|
| Length: | 5m | Thickness: | 0.8mm |
| Color: | Red | Type: | Self-fusing |
| Temperature: | 180℃ | Application: | Cable Insulation |
| High Light: | Electrical Tape Cold Shrink Cable Accessories,Heat Resistant Silicone Electrical Tape,Self Fusing Rubber Electrical Tape |
||
Heat Resistant Silicone Rubber Electrical Tape Self Fusing For Cable Insulation Protection
| Product name |
Length (±0.05)M |
Width (±1.5)mm |
Thickness (±0.05)mm |
Parameters |
| Heat Resistant Silicone Rubber Electrical Tape | 5 | 50 | 0.5 | See below chart |
| Heat Resistant Silicone Rubber Electrical Tape | 5 | 50 | 0.8 | See below chart |
Heat Resistant Silicone Rubber Electrical Tape Technical Parameters:
| No. | Items | Test standard | Unit | Results |
| 1 | Hardness | GB/T 531.1-2008 | Shores A | 50±10 |
| 2 | Tensile strength | GB/T 528-2009 | Mpa | ≥4.5 |
| 3 | Elongation at break | GB/T 528-2009 | % | ≥350 |
| 4 | Dielectric coefficient | GB/T1408.1-2006 | KV/mm | ≥22 |
| 5 | Volume resistivity | GB/T1410-2006 | Ω.cm | ≥1.3*1015 |
| 6 | Self-adhesive | ASTM D2148 | N/cm | >3.5 |
| 7 | Water absorption | % | <0.9 | |
| 8 | density | GB/T 20631.2 | g/cm3 | <1.5 |
| 9 | Flame retardant | grade | UL-94 | V0 |
| 10 | Heat resistant temperature | 180 | ||
| 11 | Withstand voltage | 15KV | ||
| 12 | Color | Red, yellow, green etc |
Features:
1: Excellent flame retardant properties, can achieve UL94-V0 flame retardant standard
2: Excellent arc resistance characteristics
3: Excellent resistance to power leakage tracking features
4: Excellent Ozone resistance characteristics
5: Excellent insulation properties
6: Good self-adhesive easy to install
7: Can use for a long time in very low temperature, nice low temperature resistance performance
8: Good heat resistance characteristics, can be used in 180℃ for long time use.
9: Excellent weather resistance properties
Application:
| No | Items |
| 1 |
Can be used for high voltage cable end with very good resistance function to electricity arc and tracking, suitable for winding on all kinds of power cable insulation materials. |
| 2 |
Can be used in insulation protection of electrical cabinets |
| 3 |
Can be applied to thermal insulation class H |
| 4 |
Can be applied to high temperature resistant cable of flame retardant requirement |
FAQ
1. Who are we?
We are professional in cold shrink industry, which applied in electrical power cable accessories industry and telecommunicatioon industry etc. Our products have been exported to America, Australia, Egypt, Taiwan, India, Indonesia, Egypt, Spain, Italy and Germany etc, Europe countries.
