Product Details:
|
| Material: | Silicone Rubber | Width: | 50mm |
|---|---|---|---|
| Length: | 5m | Thickness: | 0.8mm |
| Color: | Yellow | Type: | Self-fusing |
| Temperature: | 180°C | Application: | Cable Insulation |
| High Light: | Cold Resistant Silicone Rubber Electrical Tape,Silicone Rubber Self Fusing Electrical Tape,Cable Insulation Protection Rubber Mastic Tape |
||
Cable Insulation Protection Cold Resistant Silicone Rubber Electrical Tape Self Fusing
| Product name |
Length (±0.05)M |
Width (±1.5)mm |
Thickness (±0.05)mm |
Parameters |
| Heat Resistant Silicone Rubber Electrical Tape | 5 | 50 | 0.5 | See below chart |
| Heat Resistant Silicone Rubber Electrical Tape | 5 | 50 | 0.8 | See below chart |
Heat Resistant Silicone Rubber Electrical Tape Technical Parameters:
| No. | Items | Test standard | Unit | Results |
| 1 | Hardness | GB/T 531.1-2008 | Shores A | 50±10 |
| 2 | Tensile strength | GB/T 528-2009 | Mpa | ≥4.5 |
| 3 | Elongation at break | GB/T 528-2009 | % | ≥350 |
| 4 | Dielectric coefficient | GB/T1408.1-2006 | KV/mm | ≥22 |
| 5 | Volume resistivity | GB/T1410-2006 | Ω.cm | ≥1.3*1015 |
| 6 | Self-adhesive | ASTM D2148 | N/cm | >3.5 |
| 7 | Water absorption | % | <0.9 | |
| 8 | density | GB/T 20631.2 | g/cm3 | <1.5 |
| 9 | Flame retardant | grade | UL-94 | V0 |
| 10 | Heat resistant temperature | 180 | ||
| 11 | Withstand voltage | 15KV | ||
| 12 | Color | Red, yellow, green etc |
Features:
1: Have good fire performance, can achieve UL94-V0 flame retardant standard
2: Excellent arc force resistance characteristics
3: Excellent resistance to power leakage tracking features
4: Excellent Ozone resistance characteristics
5: Excellent insulation properties
6: Good sticker make installation easier
7: Can use for a long time in very low temperature, nice low temperature resistance performance
8: Good heat resistance characteristics, can be used in 180℃ for long time use.
9: Excellent weather resistance properties
Application:
| No | Items |
| 1 | Can be used for high voltage cable end with very good resistance function to electricity arc and tracking, suitable for winding on all kinds of power cable insulation materials. |
| 2 | Can be used in insulation protection of electrical cabinets |
| 3 | Can be applied to thermal insulation class H |
| 4 | Can be applied to high temperature resistant cable of flame retardant requirement |
