High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape

High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape
High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape
High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape

Large Image :  High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape

Product Details:
Place of Origin: CHINA
Brand Name: ZKCS
Certification: ROSH 2.0
Model Number: EPR-5005/8/3
Payment & Shipping Terms:
Minimum Order Quantity: 1000pes
Packaging Details: carton box
Delivery Time: 20-30days
Supply Ability: 5000pes/month

High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape

Description
Material: Silicone Rubber Width: 25/50mm
Length: 5m Thickness: 03/0.5/0.8mm
Color: Yellow,green,red,black Or Customized Type: Self-fusing
Temperature: 180°C Application: Cable Insulation
High Light:

Self-Fusing Silicone Rubber Electrical Tape

,

silicone rubber tape

,

Self-bonding silicone rubber wrap

High-temperature arc and track-resistant tape composed of self-fusing silicone rubber tape

Product Color Normal Specification (W*T*L)
ZKST-5005-R Red 50mm*0.5mm*5m
ZKST-5005-Y Yellow 50mm*0.5mm*5m
ZKST-5005-G Green 50mm*0.5mm*5m
ZKST-5005-B Black 50mm*0.5mm*5m
ZKST-5008-R Red 50mm*0.8mm*5m
ZKST-5008-Y Yellow 50mm*0.8mm*5m
ZKST-5008-G Green 50mm*0.8mm*5m
ZKST-5008-B Black 50mm*0.8mm*5m
ZKST-2503-R Red 25mm*0.3mm*5m
ZKST-2503-Y Yellow 25mm*0.3mm*5m



Self fusing silicone rubber electrical tape resistance to extreme low and high temperature​ Technical Parameters:

No. Items Test standard Unit Results
1 Hardness GB/T 531.1-2008 Shores A 50±10
2 Tensile strength GB/T 528-2009 Mpa ≥4.5
3 Elongation at break GB/T 528-2009 % ≥350
4 Dielectric coefficient GB/T1408.1-2006 KV/mm ≥22
5 Volume resistivity GB/T1410-2006 Ω.cm ≥1.3*1015
6 Self-adhesive ASTM D2148 N/cm >3.5
7 Water absorption   % <0.9
8 density GB/T 20631.2 g/cm3 <1.5
9 Flame retardant grade UL-94 V0
10 Heat resistant temperature     180
11 Withstand voltage     15KV
12 Color     Red, yellow, green etc





Features:

1. Excellent arc resistance.

2. Excellent tracking resistance.

3. Excellent ozone resistance.

4. Excellent insulation properties.

5. Good self-adhesiveness, easy to install by hand.

6. It can be used for a long time at extremely low temperature, and has excellent low temperature resistance.

7. Very good temperature resistance, can be used for a long time at 180 ℃.

8. Excellent weather resistance.



Application:

1. It can be applied to high-voltage cable heads to play a good role in anti-arc and anti-leakage tracking. It is suitable for wrapping on power cables of various insulation materials.

2. It can be used for insulation protection in electrical cabinets.

3. It can be applied to H-class heat-resistant insulation.

4. As an overwrap for protection of terminating high-voltage cables against arcing and
tracking.
