Insulating tube Silicone cold shrink connector for cable protection

Insulating tube Silicone cold shrink connector for cable protection
Insulating tube Silicone cold shrink connector for cable protection
Insulating tube Silicone cold shrink connector for cable protection Insulating tube Silicone cold shrink connector for cable protection Insulating tube Silicone cold shrink connector for cable protection

Large Image :  Insulating tube Silicone cold shrink connector for cable protection

Product Details:
Place of Origin: CHINA
Brand Name: ZKCS
Certification: ROHS
Model Number: Customized
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 0.8-2.2USD/PCS
Packaging Details: 50pcs or 100pcs/carton
Delivery Time: 20-30days after receiving 40% deposit
Payment Terms: L/C, T/T
Supply Ability: 100000pcs/month

Insulating tube Silicone cold shrink connector for cable protection

Description
Material: Silicone Color: Black Or Grey
Length: Customized Name: Cold Shrink Tube
Application: Insulation Protection Product Name: Insulating Tube Silicone Cold Shrink Connector For Cable Protection
Packing: Carton Free Samples: Yes
High Light:

1KV EPDM Cold Shrink Tubing

,

telecom industry Cold Shrink Tubing

,

Cable Joint EPDM Cold Shrink Tube

Product name:

Insulating tube Silicone cold shrink connector for cable protection



Description:

Cold shrink tubing is a fast and easy way to weatherproof a RF coax connection for cell site,Unlike heat shrink tubing,it can create a permanent seal without applying heat ,so it is also known as no-heat shrink tubing.

Simply position the pre -expanded tubing over the connection that the protecting and pull the rip cord,the tubing will shrink and compresses to form a weatherproof seal.





Features:



1.Simple installation.

2. No tool or heat required.

3. Seals tight, retains its resiliency and pressure even after years of aging and exposure.

4. Resists acids and alkalies.

5. Resists ozone and ultraviolet light.

6. Operating temperature range- EPDM: -60℃ ~ 150℃.

                                                   Silicone: -50℃~200℃




Applications
Primary electrical insulation for all solid dielectric (rubber and plastic) insulated wire and cable splices rated to 1000volts





Insulating tube Silicone cold shrink connector for cable protection 0



Insulating tube Silicone cold shrink connector for cable protection 1

Insulating tube Silicone cold shrink connector for cable protection 2



Insulating tube Silicone cold shrink connector for cable protection 3

Introduction:



 EPDM Cold Shrink Tubes are a series of open-ended, tubular rubber sleeves, which are factory expanded and assembled onto a removable core. They are supplied for field installation in this pre stretched condition. The core is removed after the tube has been positioned for installation over an in-line connection terminal link allowing the tube to shrink and form a waterproof seal. The insulating tube is made of EPDM rubber which contains no chlorides or sulphurs.



Material technical parameters:
No Items Test method Unit Test standard Remarks
1 Hardness (Shore A) GB/T 531.1-2009 Shore A 43±5
2 Tensile strength GB/T 528-2009 Mpa 8±3
3 Break elongation GB/T 528-2009 % 800±200
4 Tear strength GB/T 529-2008 kN/mm 38±5
5 Volume resistivity GB/T 2439-2001 Ω•cm ≥1013
6 dielectric strength GB/T 1695-2005 MV/m ≥18
7 dielectric Constant(50Hz) GB/T 1693-2007 / ≤8
