Product Details:
|
Color: | Black,Grey | Material: | Silicone Rubber |
---|---|---|---|
Thickness: | 2.0mm | Type: | Cold Shrink |
Product Name: | Cold Shrink Stress Cone Silicone | Feature: | Waterproof,seal,anti-scratch |
Keyword: | Cold Shrink Tube,silicone Cold Shrink Tube, | ||
Highlight: | Grey Cold Shrink Stress Cone,jumper Connector Cold Shrink Stress Cone,Insulation Cold Shrink Stress Cone |
Product name:
Grey Cold Shrink Stress Cone Silicone Rubber Material For 1/2 Jumper Connector
■Suitable scope
Cold shrink tubing is very useful when environmental factors play a role in your application. With its ease of installation, it’s a great alternative to heat shrink tubing. It also covers a wide range of cables and conductor types, including connectors.
Cold shrink tubing is tubing that shrinks in normal temperatures, so there is no need to heat the tubing to shrink it. It’s supplied on a removable core in a pre-stretched shape. The inner core is removed during installation, allowing the tubing to narrow down around the cables, allowing a tight and compact installation.
With cold shrink tubing, it’s easy to insulate wires, connections, repair wires, and bundle wires together. Although it has the same functions as heat shrink tubing, cold shrink tubing should be considered when the environment is potentially explosive or flammable and safety is a concern. It’s also suitable for limited spaces that you may encounter in many industrial applications.
Products Features
◆Dual layer structure,design for 1/2'
◆ Installation Easily
◆ Applicable to a variety of jumpers
◆ Waterproofness IPX8
Rubber Parameters
Properties | Test Method | Typical Value |
Color | / | Light grey |
Ultimate Tensile | ASTM D412-75 | 9.0MPa |
Ultimate Elongation | ASTM D412-75 | 750% |
Tear Resistance | ASTM D624C-73 | 30KN/m |
Fungus Resistance | ASTM G21 28 days exposure | No Growth |
Dielectric Strength | ASTM D149-75 @1.75 Original | 21KV/m |
7days in water at 90℃ | 20.5KV/m | |
Volume resistance | ASTM D257 | 3.4×1015Ohm.cm |
All values are averages and are not intended for specification purposes.
Applicable reference pics
