High Voltage EPR Tape 23# Self Fusing Electrical Insulation

High Voltage EPR Tape 23# Self Fusing Electrical Insulation
High Voltage EPR Tape 23# Self Fusing Electrical Insulation

Large Image :  High Voltage EPR Tape 23# Self Fusing Electrical Insulation

Product Details:
Place of Origin: China
Brand Name: ZKCS
Certification: ROHS / CE / SGS or according to customers' requirements
Payment & Shipping Terms:
Minimum Order Quantity: 10rolls
Price: $1.68-$4.67/roll
Packaging Details: Standard Exporting Carton Box or according to customers' requirements
Delivery Time: 7-10days for sample orders;20-30days for bulk order
Payment Terms: T/T, D/P, L/C
Supply Ability: 30000pcs/month for normal products;18000pcs/month for customized products

High Voltage EPR Tape 23# Self Fusing Electrical Insulation

Description
Product Name: High Voltage Tapes Material: EPR
Size: 19*0.76*9.15m Color: Black
Adhensive Side: Single Sided Thickness: 0.76mm
Rated Voltage: 69KV
High Light:

Rubber Splicing Tape

,

Waterproof Rubber Splicing Tape

,

scotch 23

EPR High Voltage Insulation Tape



Which is a kind of Ethylene propylene rubber tape with a thickness of 0.76mm. It has excellent self-fusing properties, high dielectric strength, and stable chemical properties. It is suitable for main insulation and cable joint protection of 69kV and below voltage levels. ZK2023 tape combines quickly and can quickly form a void-free, electrically stable sealing layer, which is an ideal choice for electrical insulation and moisture-proof and waterproof.



Product Model No. Normal Specification
High Voltage Insulation Tape ZK2023 19mm*0.76mm*9.15m
25.4mm*0.76mm*5m
38mm*0.76mm*9.15m
51mm*0.76mm*9.15m
Technical parameters
Performance Typical data Test method
Tensile strength 3.22-3.83MPa ASTM D 4325
Elongation at break 850% ASTM D 4325
dielectric strength 35.16KV/mm ASTM D 4325
volume resistivity 3.5×1015Ωcm ASTM D 1000
Heat aging(130℃168h) Pass ASTM D 4325
Ozone aging Pass ASTM D 4388
UV aging Pass ASTM D 4325
Xenon lamp Pass ISO 4892-2
