Waterproof Silicone Cold Shrink Tube With Mastic

Waterproof Silicone Cold Shrink Tube With Mastic
Waterproof Silicone Cold Shrink Tube With Mastic
Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic Waterproof Silicone Cold Shrink Tube With Mastic

Large Image :  Waterproof Silicone Cold Shrink Tube With Mastic

Product Details:
Place of Origin: CHINA
Brand Name: ZKCS
Certification: ROHS 2.0
Model Number: ZKCS-CS-2.0
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: customized
Packaging Details: 50pcs or 100pcs/carton
Delivery Time: 10-20day
Payment Terms: L/C,D/P,T/T
Supply Ability: 100000 pcs
Contact Now Chat Now

Waterproof Silicone Cold Shrink Tube With Mastic

Description
Material: High-quality Silicone + Premium Mastic Waterproof Grade: IP68
Installation Method: Cold Shrink, No Heating Required Aging Resistance: Pass 1000 Hours UV Aging Test, No Cracking Or Deformation
Highlight:

Arctic Adaptable

,

No Breakage

,

No Mastic Overflow

Product Detail


Waterproof Silicone Cold Shrink Tube With Mastic.A professional waterproof and sealing solution for cable connections, specially designed for outdoor and industrial scenarios where reliable insulation and water resistance are critical. Waterproof Silicone Cold Shrink Tube With Mastic integrates high-quality silicone material and premium mastic, ensuring tight sealing and long-term stability, perfectly solving the points of cable joint leakage, aging and poor insulation.


Product Features


  • Waterproof Silicone Cold Shrink Tube With Mastic good expanding strength and toughness, to ensure that the cable installation of the tube does not appear broken phenomenon;
  • Good low temperature brittleness, can be installed in the Arctic area, no broken;
  • Waterproof Silicone Cold Shrink Tube With Mastic good high temperature resistance, can be in the hot area, product no deformation;
  • Suits for an extensive range of cable sizes because of the shrinkage
  • Simple installation, requires no special heating tools , and adhesive to seal the connections



Product Application


Ideal for telecommunication base stations, CATV systems, power engineering and outdoor cable laying, Waterproof Silicone Cold Shrink Tube With Mastic is easy to install without heating, saving time and labor costs for on-site construction. The built-in mastic of Waterproof Silicone Cold Shrink Tube With Mastic solidifies firmly without overflowing, forming a seamless seal on the inner wall of cable joints, effectively preventing rainwater, dust and moisture from infiltrating, thus protecting cables from damage and extending their service life.
With excellent aging resistance, weather resistance and high-temperature resistance, Waterproof Silicone Cold Shrink Tube With Mastic can adapt to harsh outdoor environments such as high temperature, low temperature, strong UV and humidity. Waterproof Silicone Cold Shrink Tube With Mastic is widely compatible with N-type connectors, DIN connectors, 1/2 jumper cables and various cable joints, providing comprehensive sealing and insulation protection for your cable system. Whether for commercial projects or industrial applications, this cold shrink tube with mastic is a cost-effective and reliable choice that meets international industry standards and brings stable performance to your projects.


Model Diameter Length after shrink Cable range Min.dia(mm) Cable range Max.dia(mm)
CSPM-28-110 28mm 110mm 6 19
CSPM-30-110 30mm 110mm 9 23
CSPM-30-140 30mm 140mm 9 23
CSPM-35-120 35mm 120mm 10 26
CSPM-40-180 40mm 180mm 11.9 34


Silicone Material Technical Data

Properties Test Typical Value
Color / Black
Ultimate tensile ASTM D412-75 9.0Mpa
Ultimate elongation ASTM D412-75 820%
Tear resistance ASTM D624C-73 30KN/m
Fungus resistance ASTM G21 28 days exposure No growth
Dielectric strength ASTM D 149-75 @ 1.75 original 7 days in water at 90℃

21KV/m

20.5KV/m
Volume resistance ASTM D257 3.4×1015Ohm.cm

All values are averages and are not intened for specification purposes


FAQ


  • Q: Can Waterproof Silicone Cold Shrink Tube With Mastic be installed in extreme cold areas?
  • A: Yes, Waterproof Silicone Cold Shrink Tube With Mastic has good low-temperature brittleness, which can be smoothly installed in the Arctic region (-55℃) without any breakage.

  • Q: Will the mastic of Waterproof Silicone Cold Shrink Tube With Mastic overflow during use?
  • A: No, the built-in premium mastic of this product will solidify firmly after installation, without overflowing, ensuring seamless sealing.

  • Q: Does Waterproof Silicone Cold Shrink Tube With Mastic require special tools for installation?
  • A: No, Waterproof Silicone Cold Shrink Tube With Mastic adopts cold shrink installation, no special heating tools are needed, and it can be installed quickly on site.

  • Q: How long is the service life of Waterproof Silicone Cold Shrink Tube With Mastic?
  • A: With excellent aging resistance and weather resistance, its service life can reach more than 10 years in normal outdoor environments.

  • Q: What cable sizes is Waterproof Silicone Cold Shrink Tube With Mastic suitable for?
  • A: It has excellent shrinkage performance , suitable for a wide range of cable sizes, and compatible with most common connectors.

  • Q: Is Waterproof Silicone Cold Shrink Tube With Mastic suitable for CATV connector sealing?
  • A: Yes, it is perfectly suitable for waterproof sealing of CATV connectors, effectively preventing moisture infiltration and ensuring stable signal transmission.

Tag:

30 KN/m Silicone Cold Shrink Tube,

Cold Shrink Tube,

9.0MPa Silicone Cold Shrink Tube
