24kV 3-Core Cold Shrink Straight Cable Joint Kit XLPE Power Cable Connector 70-120mm² Silicone Rubber

24kV 3-Core Cold Shrink Straight Cable Joint Kit XLPE Power Cable Connector 70-120mm² Silicone Rubber 24kV 3-Core Cold Shrink Straight Cable Joint Kit XLPE Power Cable Connector 70-120mm² Silicone Rubber 24kV 3-Core Cold Shrink Straight Cable Joint Kit XLPE Power Cable Connector 70-120mm² Silicone Rubber
Product Details:
Place of Origin: Guangdong, China
Brand Name: WNRLN
Certification: ISO 9001:2015, IEC 60502-4
Model Number: CSJ-24/3C-120-SI
Payment & Shipping Terms:
Minimum Order Quantity: 10 Sets
Price: USD 30-65 / Set
Packaging Details: Standard export carton with inner EPE foam cushion, waterproof PE vacuum bag, plywood pallet
Delivery Time: 5-15 working days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 5000 Sets per Month
Contact Now Chat Now

24kV 3-Core Cold Shrink Straight Cable Joint Kit XLPE Power Cable Connector 70-120mm² Silicone Rubber

Description
Rated Voltage: 24kV (Um=25kV) Conductor Size: 70-120mm²
Number Of Cores: 3-Core Insulation Material: Silicone Rubber (HTV)
Connector Type: Straight Through Joint Cable Type: XLPE Power Cable
Installation Method: Cold Shrink (No Heat Required) Operating Temperature: -60°C To +180°C
Short Circuit Rating: 40kA / 1 Sec Impulse Withstand Voltage: 125kV Peak
Highlight:

24kV Silicone Cable Joint

,

High Temp Silicone Connector

,

XLPE Straight Joint 24kV

24kV Silicone Cold Shrink Straight Cable Joint Kit – 3-Core XLPE Power Cable Connector

Product Overview

The WNRLN CSJ-24/3C-120-SI is a premium 24kV silicone cold shrink straight cable joint kit designed for 3-core XLPE insulated power cables with conductor sizes 70mm² to 120mm². Utilizing high-temperature vulcanized (HTV) silicone rubber insulation, this joint kit delivers exceptional thermal stability up to +180°C, making it the ideal choice for demanding industrial environments, high-ambient substations, and regions with extreme temperature swings.

Key Features

  • HTV Silicone Rubber Insulation – Superior thermal resistance from -60°C to +180°C continuous operation, far exceeding EPDM limits. Excellent UV, ozone, and corona discharge resistance for outdoor and high-altitude installations.
  • 24kV Rated Voltage – Designed and tested for 24kV (Um=25kV) medium voltage power distribution per IEC 60502-4.
  • Cold Shrink Installation – Pre-stretched silicone body on removable spiral core. Pull out the core for instant, uniform contraction – no heat, no gas, no tools.
  • 3-Core Straight Joint Design – Integrated three-phase connector with stress control, insulation, shielding, and outer sealing in one compact assembly.
  • Wide Conductor Range – Compatible with 70-120mm² sector-shaped or round stranded copper/aluminum conductors.
  • Hydrophobic Surface – Silicone rubber naturally repels water and resists tracking, providing superior pollution performance in coastal and high-humidity environments.
  • IP68 Sealed – Triple-layer moisture barrier ensures reliable operation in direct burial and submerged applications.
  • Fast Installation – Typical joint completion under 50 minutes by a trained two-person crew.

Applications

  • High-temperature industrial plants (steel mills, foundries, glass factories)
  • Coastal and offshore wind farm collector grids
  • High-altitude substation cable interconnections
  • Underground MV distribution in tropical climates
  • Mining and chemical processing power systems
  • Cable repair in fire-resistant circuits

Technical Specifications

Rated Voltage (U0/U)12/20kV (24kV class, Um=25kV)
Conductor Size Range70mm² – 120mm²
Number of Cores3-Core
Insulation MaterialHTV Silicone Rubber
Connector TypeStraight Through Joint (In-line)
Cable Insulation TypeXLPE (Cross-Linked Polyethylene)
Installation MethodCold Shrink – Pull-out Core, No Heat Required
Operating Temperature-60°C to +180°C (Continuous)
Short Circuit Thermal Rating40kA / 1 second
Impulse Withstand Voltage125kV Peak (1.2/50μs waveform)
Power Frequency Withstand55kV / 5 minutes
Partial Discharge<10pC at 1.73U0 (20.7kV)
Tracking ResistanceClass 1A 4.5 (IEC 60587)
Ingress ProtectionIP68 (Submersion Ready)
Standards ComplianceIEC 60502-4, IEEE 404

Kit Contents

  • 3 x Cold Shrink Straight Joint Bodies (HTV Silicone, one per phase)
  • 1 x Cold Shrink Outer Jacket Sleeve (Silicone)
  • 3 x Shear Bolt Connectors (tinned copper, 70-120mm²)
  • 1 x Roll Silicone Mastic Sealing Tape
  • 3 x Copper Mesh Screen Socks
  • 1 x Constant Force Spring Set
  • 1 x Roll Abrasive Cloth
  • 3 x Cleaning Wipes
  • 1 x Installation Instruction Manual

Quality Assurance

Every WNRLN silicone cold shrink joint undergoes 100% routine testing including partial discharge measurement, AC voltage withstand, thermal cycling, and dimensional inspection. Our ISO 9001:2015 certified facility ensures batch-to-batch consistency. Type test reports per IEC 60502-4 available on request.

Contact our sales team today for pricing, custom silicone formulations, or OEM requirements. Volume discounts available for project orders.
